| Model | AL-SC10 | AL-SC20 | AL-SC30 |
|---|---|---|---|
| Power | 10W | 20W | 30W |
| Control Function | MPPT intelligent controller | MPPT intelligent controller | MPPT intelligent controller |
| Working Mode | 2H-100%, 2H-50%, 20%-Dawn | 2H-100%, 2H-50%, 20%-Dawn | 2H-100%, 2H-50%, 20%-Dawn |
| LEDs | 5050 | 5050 | 5050 |
| Efficacy (LM/W ±3%) | 200 LM/W | 200 LM/W | 200 LM/W |
| Luminous Flux | 2000 | 4000 | 6000 |
| Lens | Polycarbonate | Polycarbonate | Polycarbonate |
| CCT | 3000K, 4000K, 5000K, 5700K, 6500K | 3000K, 4000K, 5000K, 5700K, 6500K | 3000K, 4000K, 5000K, 5700K, 6500K |
| CRI | 70Ra | 70Ra | 70Ra |
| IP Rating | IP65 | IP65 | IP65 |
| Housing | Aluminium + PC | Aluminium + PC | Aluminium + PC |
| Mounting | Round Pole (60mm) | Round Pole (60mm) | Round Pole (60mm) |
| Painting | Black | Black | Black |
| Solar Panel | 35W | 35W | 35W |
| Li-Ion Battery | 76.8Wh | 153.6Wh | 230.4Wh |
| Charging Time | 5-7 Hours | 6-8 Hours | 6-8 Hours |
| Run Time (Full Power) | 7.6 Hours | 7.6 Hours | 7.6 Hours |
| Working Temp | -10°C to 60°C | -10°C to 60°C | -10°C to 60°C |
| Maximum Autonomy | Operate 2 to 3 Days under Intelligent Mode | Operate 2 to 3 Days under Intelligent Mode | Operate 2 to 3 Days under Intelligent Mode |
| Size | 570*370*180mm | 570*370*180mm | 570*370*180mm |
| Net Weight | 4.8kg | 5.4kg | 6kg |
| Warranty | 5 Years | 5 Years | 5 Years |
| Recommended Installation Height | 3 to 4 Mtr | 3 to 6 Mtr | 5 to 7 Mtr |
